P-CSCF Discovery and Monitoring

Dynamic P-CSCF Server Discovery with Real-Time Monitoring

OmniPGW by Omnitouch Network Services

Overview

P-CSCF (Proxy Call Session Control Function) Discovery and Monitoring provides dynamic discovery of IMS P-CSCF servers using DNS SRV queries with real-time SIP OPTIONS health checking. This feature enables:

Per-Rule P-CSCF Discovery: Different P-CSCF servers for different traffic types
Automatic Monitoring: Background process continuously monitors DNS resolution (every 60 seconds)
SIP OPTIONS Health Checks: Verifies P-CSCF servers are alive via SIP OPTIONS pings
- TCP First: Attempts SIP OPTIONS via TCP (preferred for reliability)
- UDP Fallback: Falls back to UDP if TCP fails
- Status Tracking: Marks each server as :up or :down based on response
Real-Time Health Tracking: Web UI displays resolution status, discovered IPs, and health status
Graceful Fallback: Three-tier fallback strategy for maximum reliability
Prometheus Metrics: Full observability via Prometheus metrics

Quick Start
Configuration
How It Works
Web UI Monitoring
Metrics and Observability
Fallback Strategy
DNS Configuration
Troubleshooting
Best Practices

Quick Start

Basic Configuration

# config/runtime.exs

# Global PCO configuration (DNS server for P-CSCF discovery)
config :pgw_c,
  pco: %{
    p_cscf_discovery_dns_server: "10.179.2.177",
    p_cscf_discovery_enabled: true,
    p_cscf_discovery_timeout_ms: 5000
  },

  upf_selection: %{
    rules: [
      # IMS Traffic - Dynamic P-CSCF discovery
      %{
        name: "IMS Traffic",
        priority: 20,
        match_field: :apn,
        match_regex: "^ims",
        upf_pool: [
          %{remote_ip_address: "10.100.2.21", remote_port: 8805, weight: 80}
        ],
        # P-CSCF Discovery FQDN (see Configuration Guide for more UPF selection rules)
        p_cscf_discovery_fqdn: "pcscf.mnc380.mcc313.3gppnetwork.org",
        # Static fallback (see PCO Configuration Guide)
        pco: %{
          p_cscf_ipv4_address_list: ["10.101.2.100", "10.101.2.101"]
        }
      }
    ]
  }

See Configuration Guide for complete UPF selection rule configuration and PCO Configuration for static P-CSCF fallback options.

Access Monitoring

Start OmniPGW
Navigate to Web UI → P-CSCF Monitor (https://localhost:8086/pcscf_monitor)
View real-time resolution status and discovered IPs

Configuration

Global P-CSCF Discovery Settings

Configure the DNS server used for P-CSCF discovery in the PCO section:

pco: %{
  # DNS server for P-CSCF discovery (separate from DNS given to UE)
  p_cscf_discovery_dns_server: "10.179.2.177",

  # Enable P-CSCF DNS discovery feature
  p_cscf_discovery_enabled: true,

  # Timeout for DNS SRV queries (milliseconds)
  p_cscf_discovery_timeout_ms: 5000,

  # Static P-CSCF addresses (global fallback)
  p_cscf_ipv4_address_list: ["10.101.2.146"]
}

Per-Rule P-CSCF FQDNs

Each UPF selection rule can specify its own P-CSCF discovery FQDN:

upf_selection: %{
  rules: [
    # IMS Traffic - IMS-specific P-CSCF
    %{
      name: "IMS Traffic",
      match_field: :apn,
      match_regex: "^ims",
      upf_pool: [...],
      p_cscf_discovery_fqdn: "pcscf.ims.mnc380.mcc313.3gppnetwork.org",
      pco: %{
        p_cscf_ipv4_address_list: ["10.101.2.100"]  # Fallback
      }
    },

    # Enterprise - Enterprise-specific P-CSCF
    %{
      name: "Enterprise Traffic",
      match_field: :apn,
      match_regex: "^enterprise",
      upf_pool: [...],
      p_cscf_discovery_fqdn: "pcscf.enterprise.example.com",
      pco: %{
        p_cscf_ipv4_address_list: ["192.168.1.50"]  # Fallback
      }
    },

    # Internet - No P-CSCF discovery (uses global config)
    %{
      name: "Internet Traffic",
      match_field: :apn,
      match_regex: "^internet",
      upf_pool: [...]
      # No p_cscf_discovery_fqdn - uses global PCO config
    }
  ]
}

How It Works

Startup Process

Application Starts
- P-CSCF Monitor GenServer initializes
- Config parser extracts all unique P-CSCF FQDNs from UPF selection rules
FQDN Registration
- Each unique FQDN is registered with the monitor
- Monitor performs initial DNS SRV query for each FQDN
- SIP OPTIONS Health Check (in parallel for all discovered servers):
  - Try TCP first (SIP/2.0/TCP on port 5060)
  - If TCP fails, fall back to UDP (SIP/2.0/UDP on port 5060)
  - Mark each server as :up (responds) or :down (no response/timeout)
- Results (IPs, health status, or errors) are cached with timestamps
Periodic Monitoring (Every 60 seconds)
- Monitor refreshes all FQDNs
- DNS queries run in background without blocking
- For each discovered server:
  - Send SIP OPTIONS via TCP (timeout: 5 seconds)
  - If TCP fails, try UDP (timeout: 5 seconds)
  - Update health status based on response
- Cache is updated with latest DNS results and health status

Session Creation Flow

DNS Query Process

The monitor uses DNS SRV records for direct P-CSCF discovery:

SRV Query: Query SRV records at _sip._tcp.{fqdn}
Priority Sorting: Sort by priority and weight
Target Extraction: Extract target hostnames from SRV records
Hostname Resolution: Resolve target hostnames to IP addresses (A/AAAA records)
Caching: Cache resolved IPs with status and timestamp

P-CSCF Address Selection Precedence

When both FQDN and static PCO are configured on a rule, FQDN takes precedence:

%{
  name: "IMS Traffic",
  p_cscf_discovery_fqdn: "pcscf.mnc380.mcc313.3gppnetwork.org",  # ← Tried FIRST
  pco: %{
    p_cscf_ipv4_address_list: ["10.101.2.100", "10.101.2.101"]   # ← Fallback
  }
}

Selection Logic:

Condition	P-CSCF Source	IPs Used	Log Message
FQDN resolves successfully	DNS Discovery (Monitor)	Discovered IPs from DNS	`"Using P-CSCF addresses from FQDN pcscf.example.com"`
FQDN fails to resolve	Rule PCO Override	Static IPs from `pco.p_cscf_ipv4_address_list`	`"Failed to get P-CSCF IPs from FQDN..., falling back to static config"`
FQDN returns empty list	Rule PCO Override	Static IPs from `pco.p_cscf_ipv4_address_list`	Fallback triggered
Monitor unavailable	Rule PCO Override	Static IPs from `pco.p_cscf_ipv4_address_list`	Error triggers fallback
No FQDN configured	Rule PCO Override or Global	Static IPs from rule or global config	Uses static config directly

Example Flow:

Session Creation for IMS Traffic Rule:
┌─────────────────────────────────────┐
│ 1. Check if FQDN configured?       │
│    ✓ Yes: "pcscf.mnc380.mcc313..." │
└──────────────┬──────────────────────┘
               │
               ▼
┌─────────────────────────────────────┐
│ 2. Query Monitor for cached IPs    │
│    Monitor.get_ips(fqdn)            │
└──────────────┬──────────────────────┘
               │
       ┌───────┴────────┐
       ▼                ▼
┌─────────────┐  ┌──────────────────┐
│ SUCCESS     │  │ FAILED/EMPTY     │
│ {:ok, ips}  │  │ {:error, reason} │
└──────┬──────┘  └────────┬─────────┘
       │                  │
       ▼                  ▼
┌─────────────┐  ┌──────────────────┐
│ Use DNS IPs │  │ Use Static PCO   │
│ [from DNS]  │  │ [from config]    │
└─────────────┘  └──────────────────┘
       │                  │
       └────────┬─────────┘
                ▼
      ┌──────────────────┐
      │ Send to UE in    │
      │ PCO message      │
      └──────────────────┘

Real-World Scenarios:

Scenario 1: DNS Discovery Works ✅

Config:
  p_cscf_discovery_fqdn: "pcscf.ims.example.com"
  pco.p_cscf_ipv4_address_list: ["10.101.2.100"]

DNS Result: [10.101.2.150, 10.101.2.151]
UE Receives: [10.101.2.150, 10.101.2.151] ← From DNS
Note: Static PCO is ignored when DNS succeeds

Scenario 2: DNS Fails, Graceful Fallback ⚠️

Config:
  p_cscf_discovery_fqdn: "pcscf.ims.example.com"
  pco.p_cscf_ipv4_address_list: ["10.101.2.100"]

DNS Result: ERROR :no_naptr_records
UE Receives: [10.101.2.100] ← From static PCO
Note: Session succeeds despite DNS failure

Scenario 3: No FQDN Configured

Config:
  # No p_cscf_discovery_fqdn
  pco.p_cscf_ipv4_address_list: ["192.168.1.50"]

UE Receives: [192.168.1.50] ← From static PCO
Note: DNS discovery not attempted

Why This Design?

Prefer Dynamic: DNS provides flexibility, load balancing, and location-aware routing
Ensure Reliability: Static fallback ensures sessions never fail due to DNS issues
Zero Manual Intervention: Automatic failover without operator involvement
Production Safe: Best of both worlds - agility with stability

Recommendation: Always configure both FQDN and static PCO for production deployments:

# ✓ RECOMMENDED: Dynamic with fallback
%{
  p_cscf_discovery_fqdn: "pcscf.ims.example.com",  # Preferred
  pco: %{
    p_cscf_ipv4_address_list: ["10.101.2.100"]     # Safety net
  }
}

# ⚠️ RISKY: Dynamic only (falls back to global PCO)
%{
  p_cscf_discovery_fqdn: "pcscf.ims.example.com"
  # No rule-specific fallback!
}

# ✓ VALID: Static only (no DNS overhead)
%{
  pco: %{
    p_cscf_ipv4_address_list: ["192.168.1.50"]
  }
}

Web UI Monitoring

P-CSCF Monitor Page

Access the monitoring interface at: https://localhost:8086/pcscf_monitor

Features:

Overview Statistics
- Total FQDNs monitored
- Successfully resolved FQDNs
- Failed resolutions
- Total discovered P-CSCF IPs
FQDN Table
- FQDN being monitored
- Resolution status (✓ Resolved / ✗ Failed / ⏳ Pending)
- Number of discovered IPs
- List of resolved IP addresses (with expandable server details)
- Last update timestamp
- Manual refresh button per FQDN
- Health Status: Each discovered server shows:
  - IP address and port
  - Hostname (from DNS SRV target)
  - Real-time health indicator (✓ Up / ✗ Down)
Refresh Controls
- Refresh All button: Trigger immediate re-query of all FQDNs
- Per-FQDN Refresh: Refresh individual FQDNs on demand
- Auto-refresh: Page updates every 5 seconds
Monitoring Metrics Dashboard
- Total FQDNs: Number of unique FQDNs registered for monitoring
- Successfully Resolved: FQDNs that successfully resolved via DNS
- Failed DNS Resolutions: FQDNs that failed to resolve
- Total P-CSCF Servers: Total number of servers discovered across all FQDNs
- ✓ Healthy (SIP OPTIONS UP): Servers responding to SIP OPTIONS health checks
- ✗ Unhealthy (SIP OPTIONS DOWN): Servers not responding to SIP OPTIONS
- DNS Success Rate: Percentage of successful DNS resolutions
- Health Check Interval: Frequency of SIP OPTIONS health checks (60s, 5s timeout)

P-CSCF Monitor Metrics Dashboard

The metrics dashboard provides real-time visibility into both DNS resolution health and P-CSCF server availability via SIP OPTIONS.

UPF Selection Page Integration

The UPF Selection page (/upf_selection) displays P-CSCF discovery status for each rule:

📌 IMS Traffic (Priority 20)
   Match: APN matching ^ims
   Pool: UPF-IMS-Primary (10.100.2.21:8805)

   🔍 P-CSCF Discovery
      FQDN: pcscf.mnc380.mcc313.3gppnetwork.org
      Status: ✓ Resolved (2 IPs)
      Resolved IPs: 10.101.2.100, 10.101.2.101

   ⚙️ PCO Overrides
      Primary DNS: 10.103.2.195
      P-CSCF (static fallback): 10.101.2.100, 10.101.2.101

Metrics and Observability

Prometheus Metrics

The P-CSCF monitoring system exposes metrics via Prometheus (port 42069 by default):

Gauge Metrics

# FQDN-level metrics
pcscf_fqdns_total                      # Total number of monitored FQDNs
pcscf_fqdns_resolved                   # Successfully resolved FQDNs (DNS succeeded)
pcscf_fqdns_failed                     # Failed FQDN resolutions (DNS failed)

# Server-level metrics (aggregate)
pcscf_servers_total                    # Total P-CSCF servers discovered via DNS SRV
pcscf_servers_healthy                  # Servers responding to SIP OPTIONS (aggregate)
pcscf_servers_unhealthy                # Servers not responding to SIP OPTIONS (aggregate)

# Server-level metrics (per-FQDN with label)
pcscf_servers_healthy{fqdn="..."}      # Healthy servers for specific FQDN
pcscf_servers_unhealthy{fqdn="..."}    # Unhealthy servers for specific FQDN

Health Check Details:

healthy: Server responded to SIP OPTIONS ping (TCP or UDP)
unhealthy: Server failed to respond to SIP OPTIONS (5s timeout per transport)

Metric Examples

DNS Resolution Metrics:

# Query successfully resolved FQDNs
pcscf_fqdns_resolved

# Calculate DNS success rate
(pcscf_fqdns_resolved / pcscf_fqdns_total) * 100

# Total discovered servers
pcscf_servers_total

SIP OPTIONS Health Metrics:

# Total healthy servers across all FQDNs
pcscf_servers_healthy

# Total unhealthy servers
pcscf_servers_unhealthy

# Calculate health check success rate
(pcscf_servers_healthy / pcscf_servers_total) * 100

# Healthy servers for a specific FQDN
pcscf_servers_healthy{fqdn="pcscf.mnc380.mcc313.3gppnetwork.org"}

# Alert on all servers down
pcscf_servers_healthy == 0 AND pcscf_servers_total > 0

Example Prometheus Alerts:

# Alert when all P-CSCF servers are down
- alert: AllPCSCFServersDown
  expr: pcscf_servers_healthy == 0 AND pcscf_servers_total > 0
  for: 5m
  labels:
    severity: critical
  annotations:
    summary: "All P-CSCF servers are unhealthy"
    description: "{{ $value }} healthy servers (0) - all failed SIP OPTIONS checks"

# Alert when more than 50% servers are down
- alert: MajorityPCSCFServersDown
  expr: (pcscf_servers_healthy / pcscf_servers_total) < 0.5
  for: 5m
  labels:
    severity: warning
  annotations:
    summary: "Majority of P-CSCF servers are unhealthy"
    description: "Only {{ $value }}% of servers are responding to SIP OPTIONS"

# Alert on DNS resolution failures
- alert: PCSCFDNSResolutionFailed
  expr: pcscf_fqdns_failed > 0
  for: 5m
  labels:
    severity: warning
  annotations:
    summary: "P-CSCF DNS resolution failures"
    description: "{{ $value }} FQDN(s) failing to resolve"

Logging

The monitor logs key events:

[info] P-CSCF Monitor started
[info] Registering 2 unique P-CSCF FQDNs for monitoring: ["pcscf.ims.example.com", "pcscf.enterprise.example.com"]
[info] P-CSCF Monitor: Registering FQDN pcscf.ims.example.com
[debug] P-CSCF Monitor: Successfully resolved pcscf.ims.example.com to 2 IPs
[warning] P-CSCF Monitor: Failed to resolve pcscf.enterprise.example.com: :nxdomain
[debug] Using P-CSCF addresses from FQDN pcscf.ims.example.com: [{10, 101, 2, 100}, {10, 101, 2, 101}]

Fallback Strategy

The system uses a three-tier fallback strategy for maximum reliability:

Tier 1: DNS Discovery (Preferred)

p_cscf_discovery_fqdn: "pcscf.ims.example.com"

Monitor queries DNS and caches resolved IPs
Session uses cached IPs if available
Advantage: Dynamic, load-balanced, location-aware

Tier 2: Rule-Specific Static PCO (Fallback)

pco: %{
  p_cscf_ipv4_address_list: ["10.101.2.100", "10.101.2.101"]
}

Used if DNS discovery fails or returns no IPs
Rule-specific static configuration
Advantage: Rule-specific fallback, predictable

Tier 3: Global PCO Configuration (Last Resort)

# Global pco config
pco: %{
  p_cscf_ipv4_address_list: ["10.101.2.146"]
}

Used if no rule-specific config and DNS fails
Global default P-CSCF addresses
Advantage: Always available, prevents session failure

Fallback Logic Example

Session matches "IMS Traffic" rule:

1. Try DNS discovery for "pcscf.ims.example.com"
   ├─ Success → Use [10.101.2.100, 10.101.2.101] ✓
   └─ Failed → Try next tier

2. Try rule's PCO override
   ├─ Configured → Use [10.101.2.100, 10.101.2.101] ✓
   └─ Not configured → Try next tier

3. Use global PCO config
   └─ Use [10.101.2.146] ✓ (Always succeeds)

DNS Configuration

DNS Server Setup

Configure DNS server with SRV and A/AAAA records for P-CSCF discovery:

; SRV records for P-CSCF (_sip._tcp prefix is queried automatically)
_sip._tcp.pcscf.mnc380.mcc313.3gppnetwork.org. IN SRV 10 50 5060 pcscf1.example.com.
_sip._tcp.pcscf.mnc380.mcc313.3gppnetwork.org. IN SRV 20 50 5060 pcscf2.example.com.

; A records
pcscf1.example.com. IN A 10.101.2.100
pcscf2.example.com. IN A 10.101.2.101

Important: OmniPGW automatically prepends _sip._tcp. to the configured FQDN. If you configure p_cscf_discovery_fqdn: "pcscf.mnc380.mcc313.3gppnetwork.org", the system will query _sip._tcp.pcscf.mnc380.mcc313.3gppnetwork.org.

SRV Record Format

SRV records follow this format:

_service._proto.domain. IN SRV priority weight port target.

Priority: Lower values have higher priority (10 before 20)
Weight: For load balancing among same priority (higher = more traffic)
Port: SIP port (typically 5060 for TCP, 5060 for UDP)
Target: Hostname to resolve to IP address

Testing DNS Configuration

# Query SRV records (note the _sip._tcp prefix)
dig SRV _sip._tcp.pcscf.mnc380.mcc313.3gppnetwork.org @10.179.2.177

# Expected output:
# _sip._tcp.pcscf.mnc380.mcc313.3gppnetwork.org. 300 IN SRV 10 50 5060 pcscf1.example.com.

# Resolve P-CSCF hostname to IP
dig A pcscf1.example.com @10.179.2.177

# Expected output:
# pcscf1.example.com. 300 IN A 10.101.2.100

Troubleshooting

Issue: FQDN Shows "Failed" Status

Symptoms:

Web UI shows ✗ Failed status
Error: :nxdomain, :timeout, or :no_naptr_records

Possible Causes:

DNS server not reachable
FQDN does not exist in DNS
No NAPTR records configured
DNS server timeout

Resolution:

# 1. Test DNS server connectivity
ping 10.179.2.177

# 2. Test NAPTR query manually
dig NAPTR pcscf.mnc380.mcc313.3gppnetwork.org @10.179.2.177

# 3. Check OmniPGW logs
grep "P-CSCF" /var/log/pgw_c.log

# 4. Verify configuration
grep "p_cscf_discovery_dns_server" config/runtime.exs

# 5. Manual refresh in web UI
# Click "Refresh" button next to failed FQDN

Issue: No IPs Returned

Symptoms:

Web UI shows "0 IPs"
Status may be ✓ Resolved or ✗ Failed

Possible Causes:

NAPTR records exist but replacement FQDNs don't resolve
Service field doesn't match IMS/SIP pattern
A/AAAA records missing

Resolution:

# Check NAPTR record service field
dig NAPTR pcscf.example.com @10.179.2.177

# Ensure service contains "SIP" or "IMS":
# CORRECT: "SIP+D2U", "x-3gpp-ims:sip"
# WRONG: "HTTP", "FTP"

# Check A/AAAA records exist
dig pcscf1.example.com A @10.179.2.177

Issue: Sessions Use Wrong P-CSCF

Symptoms:

UE receives unexpected P-CSCF addresses
Static fallback used instead of discovered IPs

Possible Causes:

DNS discovery failed but fallback is working
Rule matching incorrect
FQDN not registered

Resolution:

# 1. Check P-CSCF Monitor page
# Verify FQDN is registered and resolved

# 2. Check session logs
grep "Using P-CSCF addresses from FQDN" /var/log/pgw_c.log

# 3. Check UPF Selection page
# Verify rule shows correct FQDN and status

# 4. Test rule matching
# Create session with specific APN and verify which rule matches

Issue: High DNS Query Latency

Symptoms:

Slow session creation
Metrics show high pcscf_discovery_query_duration_seconds

Possible Causes:

DNS server performance issues
Network latency to DNS server
Timeout too high

Resolution:

# Reduce query timeout
pco: %{
  p_cscf_discovery_timeout_ms: 2000  # Reduce from 5000ms
}

# Consider using closer DNS server
pco: %{
  p_cscf_discovery_dns_server: "10.0.0.10"  # Local DNS
}

Best Practices

1. DNS Server Selection

Use Dedicated DNS Server

pco: %{
  # Dedicated DNS for P-CSCF discovery (not the same as UE DNS)
  p_cscf_discovery_dns_server: "10.179.2.177",

  # UE DNS servers (given to mobile devices)
  primary_dns_server_address: "8.8.8.8",
  secondary_dns_server_address: "8.8.4.4"
}

Why?

Separate concerns: UE DNS vs. internal IMS DNS
Different access policies and security
Independent scaling and reliability

2. Always Configure Static Fallback

%{
  p_cscf_discovery_fqdn: "pcscf.ims.example.com",  # Preferred
  pco: %{
    p_cscf_ipv4_address_list: ["10.101.2.100"]  # Required fallback
  }
}

Why?

Ensures sessions succeed even if DNS fails
Graceful degradation
Meets SLA requirements

3. Use Specific FQDNs per Traffic Type

rules: [
  # IMS
  %{
    name: "IMS",
    match_regex: "^ims",
    p_cscf_discovery_fqdn: "pcscf.ims.mnc380.mcc313.3gppnetwork.org"
  },

  # Enterprise
  %{
    name: "Enterprise",
    match_regex: "^enterprise",
    p_cscf_discovery_fqdn: "pcscf.enterprise.example.com"
  }
]

Why?

Different P-CSCF pools per service
Better load distribution
Service-specific routing

4. Monitor DNS Query Performance

# Alert on high P-CSCF query latency
alert: HighPCSCFQueryLatency
expr: histogram_quantile(0.95, pcscf_discovery_query_duration_seconds_bucket) > 2
for: 5m
labels:
  severity: warning
annotations:
  summary: "P-CSCF DNS queries are slow (p95 > 2s)"

5. Regular DNS Health Checks

Web UI: Check P-CSCF Monitor page daily
Metrics: Monitor pcscf_monitor_fqdns_failed metric
Logs: Watch for DNS errors
Testing: Periodically verify DNS records exist

6. Configure Appropriate Timeout

# Production: Balance reliability vs. latency
pco: %{
  p_cscf_discovery_timeout_ms: 5000  # 5 seconds
}

# High-performance: Favor speed, rely on fallback
pco: %{
  p_cscf_discovery_timeout_ms: 2000  # 2 seconds
}

7. Use DNS Redundancy

Configure primary and secondary DNS:

# Primary P-CSCF DNS
pcscf.mnc380.mcc313.3gppnetwork.org. IN NAPTR 10 50 "s" "SIP+D2U" "" _sip._udp.pcscf1.example.com.

# Secondary P-CSCF DNS
pcscf.mnc380.mcc313.3gppnetwork.org. IN NAPTR 20 50 "s" "SIP+D2U" "" _sip._udp.pcscf2.example.com.

PCO Configuration - Protocol Configuration Options, DNS and P-CSCF settings
Configuration Guide - Complete OmniPGW configuration reference
Monitoring - Metrics, logging, and observability
Session Management - Session lifecycle and PCO delivery
PFCP Interface - User Plane Function communication

Back to Main Documentation

OmniPGW P-CSCF Monitoring - by Omnitouch Network Services

Overview​

Table of Contents​

Quick Start​

Basic Configuration​

Access Monitoring​

Configuration​

Global P-CSCF Discovery Settings​

Per-Rule P-CSCF FQDNs​

How It Works​

Startup Process​

Session Creation Flow​

DNS Query Process​

P-CSCF Address Selection Precedence​

Web UI Monitoring​

P-CSCF Monitor Page​

UPF Selection Page Integration​

Metrics and Observability​

Prometheus Metrics​

Gauge Metrics​

Metric Examples​

Logging​

Fallback Strategy​

Tier 1: DNS Discovery (Preferred)​

Tier 2: Rule-Specific Static PCO (Fallback)​

Tier 3: Global PCO Configuration (Last Resort)​

Fallback Logic Example​

DNS Configuration​

DNS Server Setup​

SRV Record Format​

Testing DNS Configuration​

Troubleshooting​

Issue: FQDN Shows "Failed" Status​

Issue: No IPs Returned​

Issue: Sessions Use Wrong P-CSCF​

Issue: High DNS Query Latency​

Best Practices​

1. DNS Server Selection​

2. Always Configure Static Fallback​

3. Use Specific FQDNs per Traffic Type​

4. Monitor DNS Query Performance​

5. Regular DNS Health Checks​

6. Configure Appropriate Timeout​

7. Use DNS Redundancy​

Related Documentation​

Overview

Table of Contents

Quick Start

Basic Configuration

Access Monitoring

Configuration

Global P-CSCF Discovery Settings

Per-Rule P-CSCF FQDNs

How It Works

Startup Process

Session Creation Flow

DNS Query Process

P-CSCF Address Selection Precedence

Web UI Monitoring

P-CSCF Monitor Page

UPF Selection Page Integration

Metrics and Observability

Prometheus Metrics

Gauge Metrics

Metric Examples

Logging

Fallback Strategy

Tier 1: DNS Discovery (Preferred)

Tier 2: Rule-Specific Static PCO (Fallback)

Tier 3: Global PCO Configuration (Last Resort)

Fallback Logic Example

DNS Configuration

DNS Server Setup

SRV Record Format

Testing DNS Configuration

Troubleshooting

Issue: FQDN Shows "Failed" Status

Issue: No IPs Returned

Issue: Sessions Use Wrong P-CSCF

Issue: High DNS Query Latency

Best Practices

1. DNS Server Selection

2. Always Configure Static Fallback

3. Use Specific FQDNs per Traffic Type

4. Monitor DNS Query Performance

5. Regular DNS Health Checks

6. Configure Appropriate Timeout

7. Use DNS Redundancy

Related Documentation
